RFC-0210：虛擬化功能轉送

/// The guest control plane allows for creating, starting, and stopping the guest.
protocol GuestLifecycle {
    /// Create a VMM configured with the provided config. This instantiates all
    /// devices and loads the kernel without starting the VCPU or device dispatch
    /// loops.
    ///
    /// `Create` must not be called after a call to `Run` until `Stop` is called.
    /// Once a guest has been stopped with a call to `Stop`, then `Create` may be
    /// called again to re-initialize the guest.
    Create(resource struct {
        guest_config GuestConfig;
    }) -> (struct {}) error GuestError;

    /// Binds to the Guest protocol for an initialized guest.
    ///
    /// This operation must be called between `Create` and `Stop`, otherwise
    /// the provided channel will be immediately closed.
    Bind(resource struct {
        guest server_end:Guest;
    }) -> (struct {}) error GuestError;

    /// Start the VCPU and device dispatch loops. This will not return until the
    /// dispatch loops exit. On a clean shutdown (either guest or client initiated)
    /// this will return success.
    ///
    /// If forced to stop by the guest manager calling stop, a SHUTDOWN_FORCED
    /// error will be returned. This will also return any runtime error that forces
    /// the guest to stop.
    ///
    /// `Run` must only be called after a call to `Create`. Once a guest is stopped with
    /// a call to `Stop`, then `Run` may not be called again until `Create` is called
    /// to re-initialize the guest. Notably, we do not support calling `Stop`
    /// and then `Run` directly; the call to `Create` after `Stop` is a requirement.
    Run() -> (struct {}) error GuestError;

    /// Stop a running VMM. Returns once the dispatch loops have stopped. After
    /// Stop returns, `Create` and then `Run` can be called again.
    Stop() -> ();
};

type GuestError = strict enum {
    /// Catch all VMM error.
    INTERNAL_ERROR = 1;

    /// A device endpoint was requested via the guest client API, but the device isn't enabled.
    DEVICE_NOT_PRESENT = 2;

    /// The config failed VMM validation for reasons such as a missing required field.
    BAD_CONFIG = 3;

    /// The VMM failed to initialize the guest object, usually due to capability routing issues
    /// or memory layout problems.
    GUEST_INITIALIZATION_FAILURE = 4;

    /// The VMM failed to initialize a device.
    DEVICE_INITIALIZATION_FAILURE = 5;

    /// The VMM failed to start a device, usually because the device component returned a failure.
    DEVICE_START_FAILURE = 6;

    /// Two or more devices have attempted to register overlapping memory ranges.
    DEVICE_MEMORY_OVERLAP = 7;

    /// Failed to connect to a required service. Check the routing in the manifest.
    FAILED_SERVICE_CONNECT = 8;

    /// Failed to add a public service.
    DUPLICATE_PUBLIC_SERVICES = 9;

    /// General error when loading the guest kernel.
    KERNEL_LOAD_FAILURE = 10;

    /// Error when starting a VCPU.
    VCPU_START_FAILURE = 11;

    /// A VCPU encountered a fatal error while running.
    VCPU_RUNTIME_FAILURE = 12;

    /// The VMM was asked to run before it was created.
    NOT_CREATED = 13;

    /// A VMM is already running. The VMM must be stopped and a new VMM must be created before it
    /// can be run again.
    ALREADY_RUNNING = 14;

    /// A running VMM was forced to stop by the VMM controller.
    CONTROLLER_FORCED_HALT = 15;
};

type GuestConfig = resource table {
    /// Type of kernel to load.
    1: kernel_type KernelType;
    /// File to load the kernel from.
    2: kernel client_end:fuchsia.io.File;
    /// File to load the initial RAM disk from.
    3: ramdisk client_end:fuchsia.io.File;
    /// File to load the dtb overlay for a Linux kernel from.
    4: dtb_overlay client_end:fuchsia.io.File;
    /// Kernel command-line to use.
    5: cmdline string:MAX;
    /// Additional kernel command-lines to append to the main command-line.
    6: cmdline_add vector<string:MAX>:MAX;
    /// The number of CPUs to provide to a guest.
    7: cpus uint8;
    /// Amount of guest memory required, in bytes. This value may be rounded up
    /// depending on the system configuration.
    8: guest_memory uint64;
    /// A list of block devices to give a guest. Cannot be changed from the
    /// command-line.
    9: block_devices vector<BlockSpec>:MAX_BLOCK_DEVICES;
    /// A list of specifications for network devices.
   10: net_devices vector<NetSpec>:MAX_NET_DEVICES;
    /// Optional virtio-wl device.
   11: wayland_device WaylandDevice;
    /// Optional virtio-magma device.
   12: magma_device MagmaDevice;
    /// Whether to add a default network device.
   13: default_net bool;
    /// Enable virtio-balloon.
   14: virtio_balloon bool;
    /// Enable virtio-console.
   15: virtio_console bool;
    /// Enable virtio-gpu.
   16: virtio_gpu bool;
    /// Enable virtio-rng.
   17: virtio_rng bool;
    /// Enable virtio-vsock.
   18: virtio_vsock bool;
    /// Enable virtio-sound.
   19: virtio_sound bool;
    /// Enable input streams (capture) for virtio-sound.
   20: virtio_sound_input bool;
    /// Host ports to listen for guest initiated vsock connections on. This can be
    /// used for simplicity if a Listener is known at config creation time, or if a
    /// Listener must be available at the moment of guest creation for timing
    /// reasons.
    /// To add a Listener after a guest starts, see HostVsockEndpoint::Listen.
   21: vsock_listeners vector<Listener>:MAX;
};

/// A `Guest` provides access to services of a guest instance.
protocol Guest {
    /// Get a guest console.
    ///
    /// The details regarding what output is produced and what input is accepted
    /// are determined by each guest, but will typically be a read/write socket
    /// with a shell.
    ///
    /// Returns ZX_ERR_UNAVAILABLE if the guest has no configured console.
    GetConsole() -> (resource struct {
        socket zx.handle:SOCKET;
    }) error zx.status;

    /// Get the socket for low-level guest debug logs.
    ///
    /// The details regarding what output is produced and what input is accepted
    /// are determined by each guest, but will typically be a read-only socket
    /// with the guest kernel's serial logs.
    GetSerial() -> (resource struct {
        socket zx.handle:SOCKET;
    }) error zx.status;

    /// Get the vsock endpoint for the guest.
    ///
    /// This endpoint can be used to register listeners for guest initiated
    /// connections, and to initiate connections from a client. If listeners need
    /// to be registered before the guest starts so that they are immediately
    /// available, set them via the `GuestConfig` instead of using this protocol.
    ///
    /// Returns error VSOCK_NOT_PRESENT if the guest was started without a vsock
    /// device.
    GetHostVsockEndpoint(resource struct {
        endpoint server_end:HostVsockEndpoint;
    }) -> (struct {}) error GuestError;

    /// Get the balloon controller endpoint for the guest.
    ///
    /// Returns error BALLOON_NOT_PRESENT if the guest was started without a
    /// balloon device.
    GetBalloonController(resource struct {
        controller server_end:BalloonController;
    }) -> (struct {}) error GuestError;
};

library fuchsia.virtualization;

@discoverable
protocol VmmLauncher {
    /// Launches a new, uninitialized virtual machine. The bound
    /// `GuestLifecycle` can be used to initialize the VM and start or stop it.
    ///
    /// The VM will be stopped and the component destroyed when the
    ///`GuestLifecycle` channel is closed.
    Launch(resource struct {
        lifecycle server_end:GuestLifecycle;
    });

    /// ... other functionality ...
};
